Abe — Internet2 Cloud Community Assistant

Abe (Answers By Experts) is a serverless RAG chatbot built for the research and education community by the research and education community (CalPoly, Internet2, and AWS). It answers questions from a curated knowledge base of webinar recordings, Confluence pages, and supporting documents from years of and hundreds of hours of presentations on cloud topics by research and education professionals. This repository (i2ccc) contains the full stack: ingestion pipeline, RAG backend, React frontend, and AWS CDK infrastructure.

Conference talk — project background and a live demo of Abe.

Scope. Abe's knowledge base is drawn from NET+ AWS, NET+ GCP, CICP, and the CCCG. Redeploying against the same content offers no benefit; the code is published so your institutions can adapt parts of the architecture to similar use cases.

Table of Contents

• Overview
• Architecture
• Prerequisites
• Deployment
• Document Ingestion
• Operations
• Optional Features
• License & Attribution

Overview

• Retrieval-augmented answers. Questions are routed through a query classifier, vector-searched against an OpenSearch Serverless index, optionally filtered to a specific cloud platform (AWS / GCP / Azure), and answered by an LLM with inline citations to source documents.
• Conversation memory. Multi-turn history is persisted per session in DynamoDB with configurable turn and character limits.
• Source attribution. Every cited claim links back to the source document in the response UI.
• Feedback capture. Thumbs up/down ratings and free-text feedback are written to DynamoDB for review.
• SSO-ready. Optional Cognito + SAML federation gates the frontend behind an institutional IdP.

Architecture

All infrastructure is defined with AWS CDK (Python) in cdk/ and deployed as a single stack.

Frontend — React + TypeScript SPA built with Vite, hosted in S3 behind CloudFront with an Origin Access Identity. WAF protects the distribution with the AWS managed common ruleset, SQL injection ruleset, and per-IP rate limiting. An optional ACM certificate enables a custom domain.

Auth (optional) — Cognito User Pool federated to a SAML IdP. The frontend uses the Authorization Code flow against the Cognito hosted UI; tokens are validated in the proxy Lambda.

API — Two API Gateway endpoints:

• A proxy Lambda fronts the chat API, validates Cognito tokens (when SAML is enabled), and injects the upstream API key from SSM Parameter Store so secrets never reach the browser.
• A RAG Lambda performs classification, retrieval, filtering, and generation against Bedrock.

Retrieval & generation — Bedrock models (configurable in config.yaml):

• Chat: moonshotai.kimi-k2.5
• Classification & document filtering: anthropic.claude-3-haiku-20240307-v1:0
• Embeddings: amazon.titan-embed-text-v2:0

OpenSearch Serverless holds the vector index. Step Functions orchestrate ingestion with configurable concurrency.

Storage — S3 for raw documents and the frontend bundle; DynamoDB for processed-file tracking, conversation history, and feedback; SSM Parameter Store for prompts and API keys.

Prerequisites

• AWS account with credentials configured and us-east-1 available (required for CloudFront / Lambda@Edge / WAF scope).
• Bootstrapped CDK environment (cdk bootstrap).
• Python 3.11+, Node.js 18+, pnpm, Docker running locally (CDK uses it to bundle Lambda dependencies).
• Bedrock model access in the deploy region for the models listed above (Console → Bedrock → Model access).

Deployment

1. Clone and install

git clone https://github.com/Internet2/i2ccc.git
cd i2ccc
python -m venv .venv
source .venv/bin/activate
pip install -r requirements.txt
cp config.yaml.example config.yaml

2. Deploy infrastructure

config.yaml ships with sensible defaults — you only need to fill in real values after the first deploy. The initial cdk deploy will succeed with placeholders for any field the stack itself produces (OpenSearch endpoint, API endpoints, table names).

cdk deploy

3. Populate config.yaml from stack outputs

The deploy prints a set of CfnOutput values. Map them into config.yaml:

CDK output	config.yaml key
OpensearchAPIEndpoint	opensearch_endpoint
RagApiEndpoint	rag_api_endpoint
ProxyAPIEndpoint	proxy_api_endpoint
FrontendBucketName	(used by deploy-frontend.sh)
DistributionId	(used by deploy-frontend.sh)
CloudFrontURL / CustomDomainURL	frontend URL

Also set api_key (API Gateway → API Keys → reveal), step_function_arn, processed_files_table, and s3_bucket_name.

A second cdk deploy is not required unless you change infrastructure-affecting fields (prompts, models, auth, custom domain, etc.).

4. Deploy the frontend

cd frontend
cp .env.example .env
# Set VITE_API_ENDPOINT to the ProxyAPIEndpoint from CDK output

From the repository root:

./scripts/deploy-frontend.sh

The script reads CDK outputs, builds the Vite bundle, syncs to S3 with cache headers tuned per asset type, and invalidates the CloudFront cache.

Document Ingestion

The pipeline accepts files dropped into s3://<bucket>/files-to-process/ and is driven by a Step Functions state machine. Ingestion is idempotent: processed files are tracked in DynamoDB and re-runs skip them unless the cache is reset.

Option A — direct S3 upload

aws s3 cp ./documents/ s3://<bucket>/files-to-process/ --recursive

Option B — Confluence + Google Drive scraper

Use this when source material lives in a Confluence space with linked Google Drive folders.

1. Atlassian API token — create one at https://id.atlassian.com/manage-profile/security/api-tokens.
2. Google service account — in the Google Cloud Console, enable the Google Drive API, create a service account, download a JSON key. Share the target Drive folders with the service account email (Viewer access).
3. LibreOffice — required for converting Office files during ingestion:

   brew install --cask libreoffice          # macOS
   sudo apt-get install libreoffice         # Debian/Ubuntu

4. Environment — in ingest_utils/confluence_processor/:

   cp names.env.copy names.env
   # Fill in GOOGLE_DRIVE_CREDENTIALS, GOOGLE_API_KEY, CONFLUENCE_API, SERVICE_ACC_SECRET_NAME
   source names.env

   Add the Confluence URLs to confluence_urls: in config.yaml.
5. Run:

   python confluence_processor.py                       # scrape asset links → CSV
   python google_drive_processor.py                     # pull files from Drive → S3
   python confluence_event_descriptions_to_s3.py        # pull page descriptions → S3

Start processing

cd ingest_utils
python run_step_function.py                  # creates the OpenSearch index if missing, then runs the state machine
python run_step_function.py --reset-cache    # forget previously-processed files and reprocess everything

Operations

Check ingestion progress

./check_processing_status.sh

Reports files in DynamoDB, recently processed files, files in S3, and the remaining backlog.

Test the chatbot

• Production frontend — the CloudFront or custom-domain URL.
• CLI — python chat_test.py
• Streamlit (legacy) — streamlit run chat_frontend.py

Response quality improves as more documents finish ingestion; partial answers are expected during the initial run.

Optional Features

These are gated by config.yaml flags and are inactive by default.

Cognito SAML SSO

Federate the frontend with an institutional SAML IdP:

enable_saml_auth: true
cognito_domain_prefix: chatbot-yourorg          # globally unique
saml_idp_name: CorporateSSO
saml_idp_metadata_url: https://idp.example.edu/metadata
saml_attribute_mapping:
  email: http://schemas.xmlsoap.org/ws/2005/05/identity/claims/emailaddress
  given_name: http://schemas.xmlsoap.org/ws/2005/05/identity/claims/givenname
  family_name: http://schemas.xmlsoap.org/ws/2005/05/identity/claims/surname

After cdk deploy, share the SAMLAcsUrl, SAMLEntityId, and SPMetadataUrl outputs with your IAM team so they can register the app as a SAML Service Provider.

Custom CloudFront domain

Both fields must be set together; the ACM certificate must be in us-east-1:

frontend_domain_name: chatbot.example.edu
frontend_certificate_arn: arn:aws:acm:us-east-1:<account>:certificate/<id>

License & Attribution

Released under the MIT License.

This project began as a fork of an AWS / Cal Poly DxHub DxHub Innovation Challenge prototype and has since been rewritten and extended by Internet2.
